指标                                    详细

成像器件                              1/2 寸IT逐行扫描CCD
像素尺寸                              8.6 x 8.3
成像器件色值                        单色黑白
有效分辨率                           752x582
相机界面                              模拟
镜头安装方式                        C-Mount
Flange Back                       17.526 mm
垂直频率                              50Hz
平频率                                 15.625kHz
外同步信号                            HD/VD
外同步频率                           +/- 1%
JITTER（颤抖值）                 低于+/- 50 nsec
同步系统                              内同步/外同步
扫描系统                              2:1隔行
增益                                    AGC自动(0-18dB)
                                          MANUAL手动（0-18dB)可选
Gamma                              ON开/OFF关
标准快门；                           1/120 to 1/10000 s
外触发快门 / 速度                 1/4 to 1/8000s
快门速度                              1/100 to 1/10000S
水平分辨率                           560TV线
最低照度                              0.3lux F1.4
输出连接口                           12PIN
信噪比                                 60dB
灵敏度                                 400 lux F11
信号系统                              CCIR标准
视频输出                              1.0 Vp-p Sync negative75 �
                                          Unbalanced
综合指标                              详细情况
尺寸(W x H x D)                  (29X 29X32mm)
重量                                    50 g (2 oz)
电源要求                              DC 12 V (+9 to 16V)
功率消耗                              1.6W
工作温度                              -10 to 50°C (14 to 122 °F)
存放温度                              -20 to 60 °C (-4 to 140 °F)
工作湿度                              20 to 80 % (无凝固情况下)
存放湿度                              20 to 95 % (无凝固情况下)
抖动抵抗限度                        10G (20 Hz to 200 Hz)
震动抵抗限度                        70 G
符合标准                              UL 1492 FCC Class A Digital Device
                                          CE (EN61326/97+A1/98)
                                          AS4251.1+A4252.1
